Raymarine i50 Depth (Digital) Display Only Dedicated Speed, Depth and Tridata for power and sail applications! The new Raymarine i50 instruments are designed to complement the all new Raymarine cSeries and eSeries multifunction displays. These stylish, dedicated-function instruments are the perfect solution for smaller power boats, yachts and rigit inflatables. Excellent viewing angles for both day and night conditions and simple, push-button controls make the Raymarine i50 instruments extremely easy to see and use. They are also simple to install thanks to the front-mount design. Key Features - Large numerals and digits
- Red backlighting for improved visibility
- SeaTalk and SeaTalkng interfaces
- NMEA2000 (compatible) interface
- Built-in transducer interface
- 110mm x 115mm footprint identical to older Raymarine ST60+ instrumentation
- Large controls for ease of use at sea
- Low power consumption
- Multiple data source support eliminates potential data conflicts
- Front mounted design for simple installation
| Nominal Voltage | 12V DC | Operating Voltage Range | 10 - 16V DC | | Power Consumption | typically <1W (display only) and 2.4W maximum with transducer connected | | Current Consumption | 45 to 65mA (display only) and 200mA maximum with transducer connected | | Operating Temperature range | -20ºC to +55ºC | Storage Temperature | | | Relative Humidity | up to 93% | Waterproofing standard | IPX6 | | Connections | 2 x SeaTalkng and transducers | Conformance | Europe 2004/108/EC |
|
